Cisco RV120W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV120W Administration Guide 50
2
that do not implement router preference. This feature is useful if there are other
RADVD-enabled devices on the LAN. The default is high.
STEP 7 Enter the MTU size. The MTU is the size of the largest packet that can be sent over
the network. The MTU is used in RAs to ensure all nodes on the network use the
same MTU value when the LAN MTU is not well-known. The default is 1500 bytes.
STEP 8 Enter the router lifetime value, or the time in seconds that the advertisement
messages will exist on the route. The default is 3600 seconds.
STEP 9 Click Save.
Configuring Router Advertisement Prefixes
To configure the RADVD available prefixes:
STEP 1 Choose Networking > IPv6 > Advertisement Prefixes.
STEP 2 Click Add.
STEP 3 Choose the IPv6 Prefix Type:
• 6to4—6to4 is a system that allows IPv6 packets to be transmitted over an
IPv4 network. It is used when an end user wants to connect to the IPv6
Internet using their existing IPv4 connection
• Global/Local/ISATAP—By using ISATAP, you can integrate IPv6 traffic into a
IPv4 network environment. ISATAP uses a locally assigned IPv4 address to
create a 64-bit interface identifier for IPv6.
STEP 4 If you chose 6to4 in Step 3, enter the Site-level aggregation identifier (SLA ID.) The
SLA ID in the 6to4 address prefix is set to the interface ID of the interface on which
the advertisements are sent.
If you chose Global/Local/ISATAP in Step 3, enter the IPv6 prefix and prefix length.
The IPv6 prefix specifies the IPv6 network address. The prefix length variable is a
decimal value that indicates the number of contiguous, higher-order bits of the
address that make up the network portion of the address.
STEP 5 Enter the prefix lifetime, or the length of time over which the requesting router is
allowed to use the prefix.
STEP 6 Click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
