Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing VPN Client Connection Status
Cisco RV120W Administration Guide 144
8
You can change the status of a connection to either establish or disconnect the
configured SAs (Security Associations).
Viewing VPN Client Connection Status
The VPN Client Connection Status page displays the status of VPN connections.
To view VPN user connection status:
STEP 1 Choose Status > VPN Client Connection Status.
STEP 2 Click Stop.
STEP 3 In the Poll Interval field, enter the number of seconds the router waits before
updating the information on this page.
STEP 4 Click Start to restart automatic refresh at the specified poll interval.
Policy Name The name of the IKE or VPN policy associated with
this SA.
Endpoint Displays the IP address of the remote VPN
gateway or client.
Kbytes The data transmitted (in KB) over this SA.
Packets The number of IP packets transmitted over this SA.
State The current status of the SA for IKE policies. The
status can be IPsec SA Established or IPsec SA
Not Established.
Action Click Connect to establish an inactive SA
connection.
Click Drop to terminate an active SA connection.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
