Cisco RV120W Administration Guide

Administering Your Cisco RV120W
Configuring the WAN Traffic Meter
Cisco RV120W Administration Guide 123
7
STEP 5 Choose the access type. The SNMP manager or trap agent can either be allowed
to read and modify all SNMP accessible settings (rwcommunity) or be given read-
only access (rocommunity).
STEP 6 Click Save.
Configuring Additional SNMP Information
To configure additional SNMP information:
STEP 1 Choose Administration > Network Management > SNMP System Information.
STEP 2 You can enter the following information:
• SysContact—Enter the name of the contact person for this router. Examples:
admin, John Doe.
• SysLocation—Enter the physical location of the router. Example: Rack #2,
4th Floor.
• SysName—The default system name is displayed. To change, click Edit and
enter a name for easy identification of the router.
STEP 3 Click Save.
Configuring the WAN Traffic Meter
The WAN traffic meter displays statistics for traffic coming from the WAN (Internet)
to the Cisco RV120W, and traffic going from the Cisco RV120W to the WAN.
To configure the WAN Traffic Meter:
STEP 1 Choose Administration > WAN Traffic Meter.
STEP 2 Under WAN Traffic Meter, to enable the display of WAN traffic statistics, check
Enable.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
