Cisco RV120W Administration Guide

Administering Your Cisco RV120W
Configuring Network Management
Cisco RV120W Administration Guide 122
7
If you chose AuthPriv, choose the type of privacy algorithm (DES or AES) and enter
the privacy password.
STEP 4 Click Save.
Adding SNMP Traps
The Trap s List Table lists IP addresses of SNMP agents to which the router will
send trap messages (notifications) and allows several operations on the SNMP
agents.
To add a new trap:
STEP 1 In the Trap Tab le, click Add.
STEP 2 Enter the IP Address of the SNMP manager or trap agent.
STEP 3 Enter the SNMP trap port of the IP address to which the trap messages will be
sent.
STEP 4 Choose the SNMP Version: v1, v2c, or v3.
STEP 5 Enter the community string to which the agent belongs. Most agents are
configured to listen for traps in the Public community.
STEP 6 Click Save.
Configuring Access Control Rules
The SNMP v1/v2c Access Control Table is a table of access rules that enables
read-only or read-write access for select IP addresses in a defined SNMP agent's
community.
To configure access control rules:
STEP 1 In the SNMP v1/v2c Access Control Table, click Add.
STEP 2 Enter the IP Address of the specific SNMP manager or trap agent on which to
create an access rule.
STEP 3 Enter the subnet mask used to determine the list of allowed SNMP managers.
STEP 4 Enter the community string to which the agent belongs. Most agents are
configured to listen for traps in the Public community.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
