Cisco RV120W Administration Guide

Configuring Virtual Private Networks (VPNs) and Security
Configuring Security
Cisco RV120W Administration Guide 108
5
To configure certificates, choose Security > SSL Certificate. You can choose the
following options:
Generating New Certificates
One of the steps in creating a certificate is to generate a certificate request from
the computer or the device that will be using the certificate. The Certificate
Signing Request (CSR) file needs to be submitted to the CA who will then
generate a certificate for this device.
To generate a certificate request:
STEP 1 Choose Security > SSL Certificate.
STEP 2 Choose Generate a New Certificate.
STEP 3 Click Generate Certificate.
STEP 4 Enter the name of the certificate request.
STEP 5 Enter the subject of the certificate request. The Subject field populates the CN
(Common Name) entry of the generated certificate. Subject names are usually
defined in the following format: CN=, OU=, O=, L=, ST=, C=. For example,
CN=router1, OU=my_company, O=mydept, L=SFO, C=US.
STEP 6 Choose the Hash Algorithm: MD5 or SHA-1. The algorithm used to sign the
certificate (RSA) is shown.
STEP 7 Enter the signature key length, or the length of the signature (512,1024, or 2048).
STEP 8 (Optional) Enter the IP address of the router.
STEP 9 (Optional) Enter the domain name of the router.
STEP 10 (Optional) Enter the e-mail address of the company contact that is used when
generating the self certificate request.
STEP 11 Click Generate. A new certificate request is created.
Importing a Certificate from a File
To import a certificate from a file (for example, if you have been given a certificate
from a CA), the file must be on a computer connected to the Cisco RV120W:

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
