Cisco RV120W Administration Guide

Configuring Virtual Private Networks (VPNs) and Security
Configuring Advanced VPN Parameters
Cisco RV120W Administration Guide 106
5
NOTE The starting IP of the PPTP client IP range is used as the PPTP server IP of the Cisco
RV120W and the remaining PPTP client IP address range is used to assign IP
addresses to PPTP clients.
Adding New VPN Users
To add new users:
STEP 1 Choose VPN > IPsec > VPN Users.
STEP 2 In the VPN Client Setting Table, click Add.
STEP 3 Check the Enabled box.
STEP 4 Enter the username.
STEP 5 Enter the password. If you want the user to be able to change the password, check
the Enabled box.
STEP 6 Under Protocol, choose the type of user:
• QuickVPN—The user is authenticated by the VPN server. See Creating
Cisco QuickVPN Client Users, page 93.
• PPTP—The user is authenticated by a PPTP server.
• XAUTH—The user is authenticated by an external authorization server, such
as a RADIUS server.
STEP 7 Click Save.
.
Configuring VPN Passthrough
VPN passthrough allows VPN traffic that originates from VPN clients to pass
through the router. For example, if you are not using a VPN that is configured on the
Cisco RV120W, but are using a laptop to access a VPN at another site, configuring
VPN passthrough allows that connection.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
