Cisco RV120W Administration Guide

Configuring Quality of Service (QoS)
Mapping CoS Settings to DSCP Values
Cisco RV120W Administration Guide 116
6
To restore the default CoS settings, click Restore Default and, when prompted,
click OK. Then, click Save.
Mapping CoS Settings to DSCP Values
NOTE Before you can map CoS settings to DSCP values, you must first enable the CoS to
Queue option. See Configuring CoS Settings, page 115 for more information.
To map CoS settings to DSCP values:
STEP 1 Choose QoS > CoS Settings > CoS to DSCP.
STEP 2 In the CoS to DSCP field, check Enable.
STEP 3 For each CoS priority level, enter the corresponding DSCP value (0–63).
The default value is 63.
STEP 4 Click Save.
To restore the default CoS to DSCP mappings, click Restore Default and, when
prompted, click OK. Then, click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
