Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing Port Triggering Status
Cisco RV120W Administration Guide 147
8
Viewing Port Triggering Status
To view the status of port triggering:
STEP 1 Choose Status > Port Triggering Status.
STEP 2 Click Refresh to display the latest port triggering information.
The Port Triggering Status window provides information on the ports that have
been opened per the port triggering configuration rules. The ports are opened
dynamically whenever traffic that matches the port triggering rules flows through
them.
The Port Triggering Status page displays the following fields:
Click Refresh to refresh the current page and obtain the latest statistics.
LAN (Local Network)
IP Address
Displays the LAN IP address of the device which
caused the ports to be opened.
Open Ports Displays the ports that have been opened so that
traffic from WAN destined to the LAN IP address
can flow through the router.
Time Remaining
Seconds
This field displays the time for which the port will
remain open when there is no activity on that port.
The time is reset when there is activity on the port.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
