Cisco RV120W Administration Guide

Administering Your Cisco RV120W
Configuring the Discovery Settings
Cisco RV120W Administration Guide 130
7
STEP 5 Under Logging Policy, choose the type of logging policy. (See Configuring
Logging Policies, page 127.) By default, only IPsec VPN logs are enabled. Others
are disabled.
STEP 6 If you want the router to send logs to a Syslog server, check the box next to a
syslog server field and enter the IP address or Internet Name of the Syslog server
in the Syslog Server field. Choose the logging policy for each syslog server. You
can configure up to 8 syslog servers.
STEP 7 Click Save.
Configuring the Discovery Settings
The Cisco RV120W supports two types of discovery protocols: Bonjour and UPnP.
Bonjour is a service advertisement and discovery protocol. Universal Plug and
Play (UPnP) is a networking protocol that allows devices to discover each other
and communicate on the network.
Configuring Bonjour
To configure Bonjour:
STEP 1 Choose Administration > Discovery Settings > Discovery - Bonjour.
STEP 2 Check the Enable box to enable Bonjour on the router. Unchecking this will disable
Bonjour.
STEP 3 In the Bonjour Interface Control Table, you can see on which VLANs Bonjour is
enabled. For example, Bonjour is by default enabled on the default VLAN ID 1. That
means that the Cisco RV120W advertises itself to all devices connected to it on
VLAN 1, and devices joining the network can connect to the Cisco RV120W. If you
have other VLANs created on your network, you can enable Bonjour on those
VLANs too. (See Configuring Virtual LAN (VLAN) Membership, page 30 for
more information.)
STEP 4 Click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
