Cisco RV120W Administration Guide

Configuring Networking
Configuring IPv6
Cisco RV120W Administration Guide 42
2
Configuring IPv6
If you have an IPv6 network, see the following sections.
Configuring the IP Mode
To configure IPv6 properties on the Cisco RV120W, set the IP mode to IPv6:
STEP 1 Choose Networking > IPv6 > IP Mode.
STEP 2 Click the IPv4 and IPv6 Dual-Stack radio button.
STEP 3 Click Save.
Configuring IPv6 WAN Settings
Configuring WAN properties for an IPv6 network differs depending on which type
of Internet connection you have. See the sections below for detailed instructions.
The Cisco RV120W can be configured to be a DHCPv6 client of the ISP for this
WAN or a static IPv6 address provided by the ISP can be assigned.
Configuring DHCPv6
When the ISP allows you to obtain the WAN IP settings via DHCP, you need to
provide details for the DHCPv6 client configuration.
STEP 1 Choose IPv6 > IPv6 WAN (Internet).
STEP 2 In the WAN (Internet) Address (IPv6) field, choose DHCPv6.
STEP 3 Choose if the DHCPv6 client on the gateway is stateless or stateful. If a stateful
client is selected, the gateway connects to the ISP's DHCPv6 server for a leased
address. For stateless DHCP, it is not necessary to have a DHCPv6 server
available at the ISP. Instead, an ICMPv6 discover message will originate from the
Cisco RV120W and is used for auto-configuration.
STEP 4 Click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
