Cisco RV120W Administration Guide

Configuring Networking
Configuring the WAN (Internet) Settings
Cisco RV120W Administration Guide 20
2
Configuring the IPv4 WAN (Internet)
STEP 1 Choose Networking > WAN (Internet) > IPV4 WAN (Internet).
STEP 2 Choose the type of Internet connection you have. The type of connection you have
determines the rest of the information you need to enter. See the sections below
for more information:
• Configuring Automatic Configuration (DHCP), page 20
• Configuring Static IP, page 21
• Configuring PPPoE, page 21
• Configuring PPTP, page 22
• Configuring L2TP, page 23
Configuring Automatic Configuration (DHCP)
If your Internet Service Provider (ISP) uses the Dynamic Host Configuration
Protocol (DHCP) to assign you an IP address, you receive a dynamic IP address
from your ISP.
To configure DHCP WAN settings:
STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).
STEP 2 From the Internet Connection Type drop-down menu, choose
Automatic Configuration - DHCP.
STEP 3 Enter MTU information. (See Configuring MTU Settings, page 24.)
STEP 4 Enter MAC Address information. (See Configuring the MAC Address, page 24.)
STEP 5 Click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
