Cisco RV120W Administration Guide

Configuring Networking
Configuring Routing
Cisco RV120W Administration Guide 37
2
• Metric—The distance to the target (usually counted in hops).
• Ref—Number of references to this route.
• Use—Count of lookups for the route. Depending on the use of -F and -C, this
is either route cache misses (-F) or hits (-C).
• Interface—Interface to which packets for this route will be sent.
• Type—Type of routing used (RIP or static).
Configuring Static Routes
You can configure static routes to direct packets to the destination network. A
static route is a pre-determined pathway that a packet must travel to reach a
specific host or network. Some ISPs require static routes to build your routing
table instead of using dynamic routing protocols. Static routes do not require CPU
resources to exchange routing information with a peer router. You can also use
static routes to reach peer routers that do not support dynamic routing protocols.
Static routes can be used together with dynamic routes. Be careful not to
introduce routing loops in your network.
To c r e a t e a s t a t i c r o u t e :
STEP 1 Select Networking > Routing > Static Routes.
STEP 2 In the Static Route Table, click Add.
STEP 3 In the Route Name field, enter the name of the route.
STEP 4 If a route is to be immediately active, check the Active check box. When a route is
added in an inactive state, it will be listed in the routing table, but will not be used
by the firewall. The route can be enabled later. This feature is useful if the network
that the route connects to is not available when you added the route. When the
network becomes available, the route can be enabled.
STEP 5 Check the Private check box to mark this route as private, which means that it will
not be shared in a Routing Information Protocol (RIP) broadcast or multicast.
Uncheck this box if the route can be shared with other firewalls when RIP is
enabled.
STEP 6 In the Destination IP Address field, enter the IP address of the destination host or
network to which the route leads. For a standard Class C IP domain, the network
address is the first three fields of the Destination LAN IP; the last field should be
zero.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
