Cisco RV120W Administration Guide

Using Cisco QuickVPN for Windows 7, 2000, XP, or Vista
Installing the Cisco QuickVPN Software
Cisco RV120W Administration Guide 151
A
Installing the Cisco QuickVPN Software
Installing from the CD-ROM
STEP 1 Insert the Cisco RV120W CD-ROM into your CD-ROM drive. After the Setup
Wizard begins, click the Install QuickVPN link.
The License Agreement window appears.
STEP 2 Click Yes to accept the agreement.
The InstallShield Wizard copies the appropriate files to the computer.
STEP 3 Click Browse and choose where to copy the files to
(for example, C:\Cisco Small Business\QuickVPN Client).
STEP 4 Click Next.
STEP 5 Click Finish to complete the installation.
Downloading and Installing from the Internet
STEP 1 Open a web browser and enter the following URL:
http://tools.cisco.com/support/downloads
STEP 2 Enter RV120W in the search box and find the QuickVPN software.
STEP 3 Save the zip file to your PC, and extract the .exe file.
STEP 4 Double-click the .exe file, and follow the on-screen instructions.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
