Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing the Wireless Statistics
Cisco RV120W Administration Guide 142
8
Wireless Information
Channel
Viewing the Wireless Statistics
The Wireless Statistics page shows a cumulative total of relevant wireless
statistics for the radio on the device.
To v i e w w i r e l e s s s t a t i s t i c s :
STEP 1 Choose Status > Wireless Statistics.
STEP 2 Click Stop.
STEP 3 In the Poll Interval field, enter the number of seconds the router waits before
updating the information on this page.
STEP 4 Click Start to restart automatic refresh at the specified poll interval.
Operating Frequency Displays the operational frequency band.
Wireless Network Mode Displays the Wi-Fi mode of the radio (for example,
N or N/G).
Channel Displays the current channel in use by the radio.
SSID The name of the SSID.
MAC Address The MAC address of the SSID.
Security The security setting for the SSID.
Encryption The encryption type used by the SSID.
Authentication The authentication type used by the SSID.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
