Cisco RV120W Administration Guide

Administering Your Cisco RV120W
Configuring the Discovery Settings
Cisco RV120W Administration Guide 131
7
Configuring UPnP
STEP 1 Choose Administration > Discovery Settings > Discovery - UPnP.
STEP 2 Check Enable to enable UPnP.
STEP 3 In the Advertisement Period field, enter the number of seconds to specify how
often this router will broadcast its UPnP information to all devices within range.
STEP 4 In the Advertisement Time to Live field, enter the number of seconds for the
advertisement to be active.
In the UPnP Interface Control Table, you can see on which VLANs UPnP is enabled.
For example, UPnP is by default enabled on the default VLAN ID 1. That means that
the Cisco RV120W advertises itself to plug and play devices connected to it on
VLAN 1, and plug and play devices joining the network can connect to the Cisco
RV120W. If you have other VLANs created on your network, you can enable UPnP
on those VLANs too. (See Configuring Virtual LAN (VLAN) Membership,
page 30 for more information.)
The UPnP Portmap Table shows IP addresses and other settings of UPnP devices
that have accessed the Cisco RV120W:
• Active—Indicates whether or not the port of the UPnP device that
established a connection is currently active by displaying Yes or No.
• Protocol—The network protocol (i.e. TCP, UDP, etc) that the device is using
to connect to the Cisco RV120W.
• Internal Port—Indicates which, if any, internal ports are opened by the UPnP
device.
• External Port—Indicates which, if any, external ports are opened by the
UPnP device.
• IP Address—The IP address of the UPnP device that is accessing this
router.
STEP 5 Click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
