Cisco RV120W Administration Guide

Configuring Networking
Configuring the WAN (Internet) Settings
Cisco RV120W Administration Guide 21
2
Configuring Static IP
If your ISP assigned you a permanent IP address, perform the following steps to
configure your WAN settings:
STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).
STEP 2 From the Internet Connection Type drop-down menu, choose Static IP.
STEP 3 Enter this information:
STEP 4 Enter MTU information. (See Configuring MTU Settings, page 24.)
STEP 5 Enter MAC Address information. (See Configuring the MAC Address, page 24.)
STEP 6 Click Save.
Configuring PPPoE
If you have a Point-to-Point Protocol over Ethernet (PPPoE) connection to the
Internet:
STEP 1 Choose Networking > WAN (Internet) > IPv4 WAN (Internet).
STEP 2 From the Internet Connection Type drop-down menu, choose PPPoE.
STEP 3 From the PPPoE Profile Name drop-down menu, choose a PPPoE profile.
If no profile is listed, click Configure Profile to create a new profile.
To see the details of available profiles, choose
Networking > WAN (Internet) > PPPoE Profiles. See Configuring PPPoE
Profiles, page 25 for more information.
STEP 4 Enter MTU information. (See Configuring MTU Settings, page 24.)
IP Address Enter the IP address of the WAN port.
Subnet mask Enter subnet mask of the WAN port.
Default Gateway Enter the IP address of the default gateway.
Primary DNS Server Enter the IP address of the primary DNS server.
Secondary DNS Server (Optional) Enter the IP address of the secondary
DNS server.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
