Cisco RV120W Administration Guide

Administering Your Cisco RV120W
Upgrading Firmware
Cisco RV120W Administration Guide 134
7
Upgrading Firmware
!
CAUTION During a firmware upgrade, do not try to go online, turn off the device, shut down
the PC, or interrupt the process in any way until the operation is complete. This
process takes about a minute, including the reboot process. Interrupting the
upgrade process at specific points when the flash is being written to may corrupt
the flash memory and render the router unusable.
You can upgrade to a newer firmware version from the Administration > Firmware
Upgrade page. To upgrade:
STEP 1 Click Browse, locate and select the downloaded firmware, and click Upload.
STEP 2 (Optional) Check the box to reset all configuration and settings to the default
values. Do not check this box if you want to keep any settings you have changed
on the router!
STEP 3 Click Start Firmware Upgrade. After the new firmware image is validated, the new
image is written to flash, and the router is automatically rebooted with the new
firmware. Choose Status > System Summary to make sure the router installed the
new firmware version.
Rebooting the Cisco RV120W
To reboot the router, choose Administration > Reboot Router. Click Reboot.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
