Cisco RV120W Administration Guide

Viewing the Cisco RV120W Status
Viewing Available L AN Hosts
Cisco RV120W Administration Guide 146
8
Viewing Available LAN Hosts
The Available LAN (Local Network) Hosts page displays information about the
devices connected to the Cisco RV120W.
To view a list of all available LAN hosts:
STEP 1 Choose Status > Available Local Network Hosts.
STEP 2 From the Filter drop-down menu, choose the interface type.
You can choose one of the following options:
STEP 3 Click Refresh to display the latest LAN host information.
The Available LAN (Local Network) Hosts page displays the following fields:
All Displays a list of all devices connected to the
router.
Wireless Displays a list of all devices connected through the
wireless interface.
Wired Displays a list of all devices connected through the
Ethernet ports on the router.
Name The name of the connected host.
IP Address The IP address of the host.
MAC Address The MAC address of the host.
Type The type of connection (for example, static or
dynamic).
Interface Type The interface type (Wired or Wireless).

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
