Cisco RV120W Administration Guide

Configuring the Wireless Network
Configuring a Wireless Distribution System (WDS)
Cisco RV120W Administration Guide 63
3
To set up a WPS-enabled device in the network:
STEP 1 Choose Wireless > WPS.
STEP 2 Choose the WPS setup method:
• Setup Using a PIN—In the WPS Setup Method section, in the Station PIN
field, enter the personal identification number (PIN) of the device you want
to connect to the network. You must log in to that device to obtain its WPS
PIN. Then click Configure via PIN. After clicking this button on the Cisco
RV120W, on the WPS-enabled device, select the necessary option to begin
WPS. The device should begin communication with the Cisco RV120W.
• Setup Using a WPS Button—If the device you want to connect has a WPS
button, push the button on the device. Then, on the Cisco RV120W, click
Configure via PBC (push button configuration).
Configuring a Wireless Distribution System (WDS)
A Wireless Distribution System (WDS) is a system that enables the wireless
interconnection of access points in a network. It allows a wireless network to be
expanded using multiple access points without the need for a wired backbone to
link them.
WDS peers are other access points in the network connected in the WDS. All
base stations in a WDS must be configured to use the same radio channel, method
of encryption (none, WEP, or WPA) and encryption keys.
To configure a WDS:
STEP 1 Choose Wireless > WDS.
STEP 2 Check the Enable box to enable WDS in the Cisco RV120W.
STEP 3 Enter a WPA Key (password) for authentication.
STEP 4 Click Save.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
