Cisco RV120W Administration Guide

Using Cisco QuickVPN for Windows 7, 2000, XP, or Vista
Using the Cisco QuickVPN Software
Cisco RV120W Administration Guide 153
A
STEP 5 To terminate the VPN tunnel, click Disconnect. To change your password, click
Change Password. For information, click Help.
STEP 6 If you clicked Change Password and have permission to change your own
password, you will see the Connect Virtual Private Connection window. Enter your
password in the Old Password field. Enter your new password in the New
Password field. Then enter the new password again in the Confirm New Password
field. Click OK to save your new password. Click Cancel to cancel your change.
For information, click Help.
NOTE You can change your password only if the Allow User to Change Password
box has been checked for that username. See Configuring VPN Users,
page 105.

Cisco RV120W Specifications

General

Ethernet LAN	Yes
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity	10
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Channels quantity	13 channels
WLAN data transfer rate (max)	300 Mbit/s
Input current	1 A
Input voltage	12 V
xDSL connection	No
Dimensions (WxDxH)	150 x 150 x 34 mm
Networking features	Fast Ethernet, WLAN, WAN
Operating temperature (T-T)	32 - 104 °F
Security algorithms	802.1x RADIUS, EAP, WPA2
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Ethernet LAN (RJ-45) ports	4
Certification	FCC B, CE, IC, Wi-Fi
Product color	Black
Storage temperature (T-T)	-20 - 70 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Weight	500 g
