6-29
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Chapter 6 Configuring the System
Configuring STP
Figure 6-6 Switches in a Hierarchical Network
3500 XL 3500 XL
2900 XL 2900 XL 2900 XL
2900 XL 2900 XL 2900 XL 2900 XL
Active link
Blocked link
Root bridge
Backbone switches
Distribution switches
Access switches
22037
