Chapter 2 Getting Started with CMS
Cluster Manager and VSM
2-4
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Figure 2-1 Visual Switch Manager
Left-click Mode to change the meaning of the port LEDs.
LEDs display the current port mode and the status of the
switch and connected RPS.
Press Ctrl, and then left-click ports to select multiple
ports. The color of the port reflects port or link status.
Right-click a port to display the port pop-up menu, and
select an option to change port-related settings.
54513
10.1.126.45
10.1.126.45
