2-5
Catalyst 2900 Series XL and Catalyst 3500 Series XL Software Configuration Guide
78-6511-05
Chapter 2 Getting Started with CMS
Cluster Manager and VSM
Figure 2-2 Cluster Manager
Right-click a switch to
display the device pop-up
menu, and select an option
to change system-related
settings.
Select a switch from the cluster
tree. The color of the switch
icon reflects switch status.
Cluster tree
54504
10.1.126.45
