DescriptionField
Path index.Pth
Hop in path index.Hop
Time distribution index.Dst
Operations completed.Comps
Sum of completion times, in milliseconds.SumCmp
Sum of completion times squared low 32 bits, in
milliseconds.
SumCmp2L
Sum of completion times squared high 32 bits, in
milliseconds.
SumCmp2H
Completion time maximum, in milliseconds.TMax
Completion time minimum, in milliseconds.TMin
The following sample output is from the show ipsla statistics aggregated command when a path discovery
operation is enabled.
Data following the hourly index is aggregated for all paths in the group during the given hourly interval.
RP/0/0/CPU0:router# show ipsla statistics aggregated 100041
Entry number: 100041
Hour Index: 13
<The following data after the given hourly index is aggregated for all paths in the group
during the given hourly interval.>
Start Time Index: 12:20:57.323 UTC Tue Nov 27 2007
Number of Failed Operations due to a Disconnect : 0
Number of Failed Operations due to a Timeout : 249
Number of Failed Operations due to a Busy : 0
Number of Failed Operations due to a No Connection : 0
Number of Failed Operations due to an Internal Error: 0
Number of Failed Operations due to a Sequence Error : 0
Number of Failed Operations due to a Verify Error : 0
<end>
RTT Values:
RTTAvg : 21 RTTMin: 19 RTTMax : 73
NumOfRTT: 2780 RTTSum: 59191 RTTSum2: 1290993
<The following data for LSP path information is available after path discovery is enabled.>
Path Information:
Path Path LSP Outgoing Nexthop Downstream
Idx Sense Selector Interface Address Label Stack
1 1 127.0.0.1 Gi0/4/0/0 192.39.1.1 677
2 1 127.0.0.1 Gi0/4/0/0.1 192.39.2.1 677
3 1 127.0.0.1 Gi0/4/0/0.2 192.39.3.1 677
4 1 127.0.0.1 Gi0/4/0/0.3 192.39.4.1 677
5 1 127.0.0.8 Gi0/4/0/0 192.39.1.1 677
Cisco IOS XR System Monitoring Command Reference for the Cisco XR 12000 Series Router, Release 4.1
244 OL-24735-01
IP Service Level Agreement Commands
show ipsla statistics aggregated
