11.3.8 Position register
Table 110.0x20 - POS - Position register
11.3.9
Table 111.0x24 - ETHRES - Error threshold register
Error threshold register
11.3.10
Table 112.0x28 - INIT - Initialisation data register
Initialisation data register
31 54 0
POSITION
0 0b00000
rw r
31: 0 Scrubber position (POSITION) - The current position of the scrubber while active,
otherwise zero.
The address bits below the burst size alignment are constant ‘0’
31 22 21 14 13 2 1 0
RECT BECT RESERVED R
E
C
T
E
B
E
C
T
E
00 000
rw rw r rw rw
31: 22 Interrupt threshold value for current scrub run correctable error count (RECT)
21: 14 Interrupt threshold value for current scrub block correctable error count (BECT)
13: 2 RESERVED
1 Scrub run correctable error count threshold enable (RECTE)
0 Scrub block correctable error count threshold enable (BECTE)
31 22 21 14 13 2 1 0
DATA
-
w
31: 0 Initialisation data (DATA) - Part of data pattern to be written in initialisation mode. A write opera-
tion assigns the first part of the buffer and moves the rest of the words in the buffer one step.
