GR740-UM-DS, Nov 2017, Version 1.7 120 www.cobham.com/gaisler
GR740
11.3.11 Second range low address register
Table 113.0x2C - RANGEL2 - Second range low address register
11.3.12
Table 114.0x30 - RANGEH2 - Second range high address register
Second range high address register
31 54 0
RLADDR
0 0b00000
rw r
31: 0 Scrubber range low address (RLADDR) - The lowest address in the range to be
scrubbed (if CONFIG.SERA = 1)
The address bits below the burst size alignment are constant ‘0’
31 54 0
RHADDR
0 0b11111
rw r
31: 0 Scrubber range high address (RHADDR) - The highest address in the range to be
scrubbed (if CONFIG.SERA = 1)
The address bits below the burst size alignment are constant ‘1’
