COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 181 www.cobham.com/gaisler
GR740
the configuration port’s registers in the middle of an RMAP write command. This needs to be consid-
ered in order to avoid a mismatch between the expected written value and actual written value.
None of the access control mechanisms mentioned in section 13.5.1.3 have any effect on the AHB
slave interface.
13.5.3 Registers
The configuration port’s registers listed in this section can be accessed either through the RMAP tar-
get, or the AMBA AHB slave interface. The address specified in table 174 is the RMAP address.
When accessed through the AHB slave interface, the address in the table should be added to the
router’s base address specified in table 7, section 2.3. Registers that exist in several identical copies,
corresponding to different addresses or ports, for example the RTR.RTPMAP registers, are only
described once. The register layout used is explained in section 1.11.
Table 174.GRSPWROUTER registers
RMAP address Register name Acronym
0x00000000 RESERVED *
0x00000004 -
0x00000030
Routing table port mapping, physical addresses 1-12 RTR.RTPMAP
0x00000034 -
0x0000007C
RESERVED *
0x00000080 -
0x000003FC
Routing table port mapping, logical addresses 32-255 RTR.RTPMAP
0x00000400 RESERVED *
0x00000404 -
0x00000430
Routing table address control, physical addresses 1-12 RTR.RTACTRL
0x00000450 -
0x0000047C
RESERVED *
0x00000480 -
0x000007FC
Routing table address control, logical addresses 32-255 RTR.RTACTRL
0x00000800 Port control, port 0 (configuration port) RTR.PCTRLCFG
0x00000804 -
0x00000830
Port control, port 1-12 (SpaceWire ports and AMBA ports) RTR.PCTRL
0x00000850 -
0x0000087C
RESERVED
0x00000880 Port status, port 0 (configuration port) RTR.PSTSCFG
0x00000884 -
0x000008B0
Port status, ports 1-12 (SpaceWire ports and AMBA ports) RTR.PSTS
0x000008D0 -
0x000008FC
RESERVED
0x00000900 -
0x00000930
Port timer reload, ports 0-12 RTR.PTIMER
0x00000950 -
0x0000097C
RESERVED
0x00000980 Port control 2, ports 0 (configuration port) RTR.PCTRL2CFG
0x00000984 -
0x00000930
Port control 2, ports 1-12 (SpaceWire ports and AMBA ports) RTR.PCTRL2
0x000009D0 -
0x000009FC
RESERVED
0x00000A00 Router configuration / status RTR.RTRCFG
0x00000A04 Time-code RTR.TC
0x00000A08 Version / instance ID RTR.VER
