GR740-UM-DS, Nov 2017, Version 1.7 222 www.cobham.com/gaisler
GR740
Table 254.0x34 - Capabilities Pointer Register
31 87 0
RESERVED Capabilities Pointer
0 0x40
rr
31: 8 RESERVED
7: 0 Capabilities Pointer - Indicates the first item in the list of capabilities of the Extended PCI Configu-
ration Space. Value: 0x40
Table 255.0x3C - Max_Lat, Min_Gnt, Interrupt Pin and Interrupt Line register
31 24 23 16 15 8 7 0
Max_Lat Min_Gnt Interrupt Pin Interrupt Line
0
0
INTA 0
rrrrw
31: 24 (Max_Lat) - NOT IMPLEMENTED, Returns zero
23: 16 (
Min_Gnt) - NOT IMPLEMENTED, Returns zero
15: 8 Interrupt Pin - Indicates INTA
7: 0 Interrupt Line
