GR740-UM-DS, Nov 2017, Version 1.7 319 www.cobham.com/gaisler
GR740
22.3.4 Interrupt mask register
Table 404.0x0C - IMASK - Interrupt mask register
22.3.5 Interrupt polarity register
Table 405.0x10 - IPOL - Interrupt polarity register
22.3.6 Interrupt edge register
Table 406.0x14- IEDGE - Interrupt edge register
31 16 15 0
RESERVED MASK
00
rrw
31: 16 RESERVED
15: 0 Interrupt mask (MASK) - 0=interrupt masked, 1=intrrupt enabled
31 16 15 0
RESERVED POL
0NR
rrw
31: 16 RESERVED
15: 0 Interrupt polarity (POL) - 0=low/falling, 1=high/rising
31 16 15 0
RESERVED EDGE
0NR
rrw
31: 16 RESERVED
15: 0 Interrupt edge (EDGE) - 0=level, 1=edge
