GR740-UM-DS, Nov 2017, Version 1.7 322 www.cobham.com/gaisler
GR740
22.3.12 Logical-OR/AND-XOR registers
Table 412.0x54-0x7C - LOR/LAND/LXOR - Logical-OR/AND/XOR registers
31 nlin nlin-1 0
RESERVED DATA
00
rw*
31: nlin RESERVED
nlin-1: 0 The logical-OR/AND/XOR registers will update the corresponding register (see table 400) accord-
ing to:
New value = <Old value> logical-op <Write data>
Note: This field has range 15:0 for the first GPIO port, GRGPIO0, and range 21:0 for the second
GPIO port, GRGPIO1.
