GR740-UM-DS, Nov 2017, Version 1.7 360 www.cobham.com/gaisler
GR740
30.3.6 PLL current configuration register
Table 459.0x14 - PLLCURCFG - PLL current configuration register
31 19 28 27 26 18 17 9 8 0
RESERVED SWTAG SPWPLLCFG MEMPLLCFG SYSPLLCFG
0 0b000010000 0b000001010 0b000010101
rrrrr
31: 29 RESERVED
28: 27 Software tag (SWTAG) - Can be used freely as tag data.
26: 18 Current SPWPLL configuration (SPWPLLCFG) - See table 32
17: 9 Current MEMPLL configuration (MEMPLLCFG) - See table 31
8: 0 Current SYSPLL configuration (SYSPLLCFG) - See table 30
