COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 378 www.cobham.com/gaisler
GR740
Table 486.0x054 - DET4 - Datation Elapsed Time 4
31 24 23 0
DET4 RESERVED
00
rr
31: 24 Datation Elapsed Time 4 (DET4) - CCSDS Time Code value (128 to 135) of local ET
counter value.
23: 0 RESERVED
Table 487. 0x060 - TRPFRX - Time-Stamp Preamble Field Rx
31 16 15 0
RESERVED TRPF
0 0x2f00
rr
31: 16 RESERVED
15: 0 Time stamp Preamble Field (TRPF) - The number of coarse and fine time implemented can be
obtained from this Preamble Field.
Table 488. 0x064 - TR0 - Time Stamp Elapsed Time 0 Rx
31 0
TR0
0
r
31: 0 Time Stamp Elapsed Time 0 Rx (TR0) - Time stamped local ET value (0 To 31) when distributed interrupt
received.
Table 489. 0x068 - TR1 - Time Stamp Elapsed Time 1 Rx
31 0
TR1
0
r
31: 0 Time Stamp Elapsed Time 1 Rx (TR1) - Time stamped local ET value (32 to 63) when distributed interrupt
received.
Table 490. 0x06C - TR2 - Time Stamp Elapsed Time 2 Rx
31 0
TR2
0
r
31: 0 Time Stamp Elapsed Time 2 Rx (TR2) - Time stamped local ET value (64 to 95) when distributed interrupt
received.
Table 491. 0x070 - TR3- Time Stamp Elapsed Time 3 Rx
31 0
TR3
0
r
31: 0 Time Stamp Elapsed Time 3 Rx (TR3) - Time stamped local ET value (96 to 127) when distributed interrupt
received.
