Only address bits with the corresponding mask bit set to ‘1’ are compared during breakpoint detec-
tion. To break on AHB load or store accesses, the LD and/or ST bits should be set.
Table 534. 0x000050, 0x000058 - ATBBA - AHB trace buffer break address registers
31 210
BADDR[31:2] RES
NR 0
rw r
31: 2 Break point address (BADDR) - Bits 31:2 of breakpoint address
10 RESERVED
Table 535. 0x000054, 0x00005C - ATBBM - AHB trace buffer break mask registers
31 210
BMASK[31:2] LD ST
NR 0 0
rw rw rw
31: 2 Breakpoint mask (BMASK) - See description above tables.
1 Load (LD) - Break on data load address
0 Store (ST) - Break on data store address
