COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 462 www.cobham.com/gaisler
GR740
D9 VSS3V3 Power/ground pin VSS3V3
D10 VDIG3V3 Power/ground pin VDIG3V3
D11 VSS3V3 Power/ground pin VSS3V3
D12 VDIG3V3 Power/ground pin VDIG3V3
D13 VSS3V3 Power/ground pin VSS3V3
D14 GPIO[15] IO LVCMOS 3.3 - GPIO
D15 GPIO[11] IO LVCMOS 3.3 - GPIO
D16 GPIO[5] IO LVCMOS 3.3 - GPIO
D17 BREAK I LVCMOS 3.3 - High Bootstrap
D18 DSU_EN I LVCMOS 3.3 - High Bootstrap
D19 WDOGN O LVCMOS 3.3 - Low Bootstrap, Open-
drain
D20 PLL_LOCKED[2] O LVCMOS 3.3 - High Bootstrap
D21 VSS2V5 Power/ground pin VSS2V5
D22 SPW_TXS_P[7] O LVDS 2.5 - Pos SpaceWire
D23 SPW_TXS_N[7] O LVDS 2.5 - Neg SpaceWire
D24 SPW_TXD_P[7] O LVDS 2.5 - Pos SpaceWire
D25 SPW_TXD_N[7] O LVDS 2.5 - Neg SpaceWire
E1 PROMIO_ADDR[18] IO LVCMOS 3.3 - PROM
E2 PROMIO_ADDR[20] IO LVCMOS 3.3 - PROM
E3 VDIG3V3 Power/ground pin VDIG3V3
E4 PROMIO_ADDR[15] O LVCMOS 3.3 - PROM
E5 PROMIO_ADDR[13] O LVCMOS 3.3 - PROM
E6 PROMIO_ADDR[1] O LVCMOS 3.3 - PROM
E7 PROMIO_DATA[7] IO LVCMOS 3.3 - PROM
E8 PROMIO_DATA[1] IO LVCMOS 3.3 - PROM
E9 VDIG3V3 Power/ground pin VDIG3V3
E10 VSS3V3 Power/ground pin VSS3V3
E11 VDIG3V3 Power/ground pin VDIG3V3
E12 AGNDPLL1V2_SYSPLL Power/ground pin PLL
E13 AGNDPLL1V2_MEMPLL Power/ground pin PLL
E14 AGNDPLL1V2_SPWPLL Power/ground pin PLL
E15 PROC_ERRORN O LVCMOS 3.3 - Low Bootstrap, Open-
drain
E16 MEM_CLKSEL I LVCMOS 3.3 - Bootstrap
E17 PLL_BYPASS[2] I LVCMOS 3.3 - High Bootstrap
E18 PLL_LOCKED[5] O LVCMOS 3.3 - High Bootstrap
E19 PLL_LOCKED[3] O LVCMOS 3.3 - High Bootstrap
E20 PLL_LOCKED[0] O LVCMOS 3.3 - High Bootstrap
E21 VSS2V5 Power/ground pin VSS2V5
E22 SPW_RXS_P[7] I LVDS 2.5 DiffTerm Pos SpaceWire
E23 SPW_RXS_N[7] I LVDS 2.5 DiffTerm Neg SpaceWire
E24 SPW_RXD_P[7] I LVDS 2.5 DiffTerm Pos SpaceWire
E25 SPW_RXD_N[7] I LVDS 2.5 DiffTerm Neg SpaceWire
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
