COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 464 www.cobham.com/gaisler
GR740
G20 VSS3V3 Power/ground pin VSS3V3
G21 VSS2V5 Power/ground pin VSS2V5
G22 SPW_RXS_P[6] I LVDS 2.5 DiffTerm Pos SpaceWire
G23 SPW_RXS_N[6] I LVDS 2.5 DiffTerm Neg SpaceWire
G24 SPW_RXD_P[6] I LVDS 2.5 DiffTerm Pos SpaceWire
G25 SPW_RXD_N[6] I LVDS 2.5 DiffTerm Neg SpaceWire
H1 PROM_CEN[1] IO LVCMOS 3.3 - Low PROM
H2 PROM_CEN[0] O LVCMOS 3.3 - Low PROM
H3 VSS3V3 Power/ground pin VSS3V3
H4 PROMIO_ADDR[27] IO LVCMOS 3.3 - PROM
H5 PROMIO_ADDR[25] IO LVCMOS 3.3 - PROM
H6 VDIG3V3 Power/ground pin VDIG3V3
H7 VSS3V3 Power/ground pin VSS3V3
H8 VDD1V2 Power/ground pin VDD
H9 GND Power/ground pin GND
H10 VDD1V2 Power/ground pin VDD
H11 GND Power/ground pin GND
H12 VDD1V2 Power/ground pin VDD
H13 GND Power/ground pin GND
H14 VDD1V2 Power/ground pin VDD
H15 GND Power/ground pin GND
H16 VDD1V2 Power/ground pin VDD
H17 GND Power/ground pin GND
H18 VDD1V2 Power/ground pin VDD
H19 VSS3V3 Power/ground pin VSS3V3
H20 VDIG3V3 Power/ground pin VDIG3V3
H21 VSS2V5 Power/ground pin VSS2V5
H22 SPW_TXS_P[5] O LVDS 2.5 - Pos SpaceWire
H23 SPW_TXS_N[5] O LVDS 2.5 - Neg SpaceWire
H24 SPW_TXD_P[5] O LVDS 2.5 - Pos SpaceWire
H25 SPW_TXD_N[5] O LVDS 2.5 - Neg SpaceWire
J1 ETH0_MDC O LVCMOS 3.3 - Ethernet
J2 ETH0_RXCLK I LVCMOS 3.3 - Ethernet
J3 VDIG3V3 Power/ground pin VDIG3V3
J4 ETH0_MDINT I LVCMOS 3.3 - Low Ethernet
J5 ETH0_CRS I LVCMOS 3.3 - High Ethernet
J6 VSS3V3 Power/ground pin VSS3V3
J7 VDIG3V3 Power/ground pin VDIG3V3
J8 GND Power/ground pin GND
J9 VDD1V2 Power/ground pin VDD
J10 GND Power/ground pin GND
J11 VDD1V2 Power/ground pin VDD
J12 GND Power/ground pin GND
J13 VDD1V2 Power/ground pin VDD
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
