COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 465 www.cobham.com/gaisler
GR740
J14 GND Power/ground pin GND
J15 VDD1V2 Power/ground pin VDD
J16 GND Power/ground pin GND
J17 VDD1V2 Power/ground pin VDD
J18 GND Power/ground pin GND
J19 VDIG3V3 Power/ground pin VDIG3V3
J20 VSS3V3 Power/ground pin VSS3V3
J21 VDIG2V5 Power/ground pin VDIG2V5
J22 SPW_RXS_P[5] I LVDS 2.5 DiffTerm Pos SpaceWire
J23 SPW_RXS_N[5] I LVDS 2.5 DiffTerm Neg SpaceWire
J24 SPW_RXD_P[5] I LVDS 2.5 DiffTerm Pos SpaceWire
J25 SPW_RXD_N[5] I LVDS 2.5 DiffTerm Neg SpaceWire
K1 ETH0_RXD[0] I LVCMOS 3.3 - Ethernet
K2 ETH0_RXD[2] I LVCMOS 3.3 - Ethernet
K3 VSS3V3 Power/ground pin VSS3V3
K4 ETH0_MDIO IO LVCMOS 3.3 - Ethernet
K5 ETH0_COL I LVCMOS 3.3 - High Ethernet
K6 VDIG3V3 Power/ground pin VDIG3V3
K7 VSS3V3 Power/ground pin VSS3V3
K8 VDD1V2 Power/ground pin VDD
K9 GND Power/ground pin GND
K10 VDD1V2 Power/ground pin VDD
K11 GND Power/ground pin GND
K12 VDD1V2 Power/ground pin VDD
K13 GND Power/ground pin GND
K14 VDD1V2 Power/ground pin VDD
K15 GND Power/ground pin GND
K16 VDD1V2 Power/ground pin VDD
K17 GND Power/ground pin GND
K18 VDD1V2 Power/ground pin VDD
K19 VSS3V3 Power/ground pin VSS3V3
K20 VDIG3V3 Power/ground pin VDIG3V3
K21 VSS2V5 Power/ground pin VSS2V5
K22 SPW_TXS_P[4] O LVDS 2.5 - Pos SpaceWire
K23 SPW_TXS_N[4] O LVDS 2.5 - Neg SpaceWire
K24 SPW_TXD_P[4] O LVDS 2.5 - Pos SpaceWire
K25 SPW_TXD_N[4] O LVDS 2.5 - Neg SpaceWire
L1 ETH0_RXD[4] I LVCMOS 3.3 - Ethernet
L2 ETH0_RXD[6] I LVCMOS 3.3 - Ethernet
L3 VDIG3V3 Power/ground pin VDIG3V3
L4 ETH0_RXD[1] I LVCMOS 3.3 - Ethernet
L5 ETH0_RXDV I LVCMOS 3.3 - High Ethernet
L6 VSS3V3 Power/ground pin VSS3V3
L7 VDIG3V3 Power/ground pin VDIG3V3
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
