COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 466 www.cobham.com/gaisler
GR740
L8 GND Power/ground pin GND
L9 VDD1V2 Power/ground pin VDD
L10 GND Power/ground pin GND
L11 VDD1V2 Power/ground pin VDD
L12 GND Power/ground pin GND
L13 VDD1V2 Power/ground pin VDD
L14 GND Power/ground pin GND
L15 VDD1V2 Power/ground pin VDD
L16 GND Power/ground pin GND
L17 VDD1V2 Power/ground pin VDD
L18 GND Power/ground pin GND
L19 VDIG3V3 Power/ground pin VDIG3V3
L20 VSS3V3 Power/ground pin VSS3V3
L21 VDIG2V5 Power/ground pin VDIG2V5
L22 SPW_RXS_P[4] I LVDS 2.5 DiffTerm Pos SpaceWire
L23 SPW_RXS_N[4] I LVDS 2.5 DiffTerm Neg SpaceWire
L24 SPW_RXD_P[4] I LVDS 2.5 DiffTerm Pos SpaceWire
L25 SPW_RXD_N[4] I LVDS 2.5 DiffTerm Neg SpaceWire
M1 ETH0_RXER I LVCMOS 3.3 - High Ethernet
M2 ETH0_GTXCLK I LVCMOS 3.3 - Ethernet
M3 ETH0_RXD[5] I LVCMOS 3.3 - Ethernet
M4 ETH0_RXD[3] I LVCMOS 3.3 - Ethernet
M5 ETH0_RXD[7] I LVCMOS 3.3 - Ethernet
M6 VDIG3V3 Power/ground pin VDIG3V3
M7 VSS3V3 Power/ground pin VSS3V3
M8 VDD1V2 Power/ground pin VDD
M9 GND Power/ground pin GND
M10 VDD1V2 Power/ground pin VDD
M11 GND Power/ground pin GND
M12 VDD1V2 Power/ground pin VDD
M13 GND Power/ground pin GND
M14 VDD1V2 Power/ground pin VDD
M15 GND Power/ground pin GND
M16 VDD1V2 Power/ground pin VDD
M17 GND Power/ground pin GND
M18 VDD1V2 Power/ground pin VDD
M19 VSS3V3 Power/ground pin VSS3V3
M20 VDIG3V3 Power/ground pin VDIG3V3
M21 VSS2V5 Power/ground pin VSS2V5
M22 SPW_TXS_P[3] O LVDS 2.5 - Pos SpaceWire
M23 SPW_TXS_N[3] O LVDS 2.5 - Neg SpaceWire
M24 SPW_TXD_P[3] O LVDS 2.5 - Pos SpaceWire
M25 SPW_TXD_N[3] O LVDS 2.5 - Neg SpaceWire
N1 ETH0_TXD[0] O LVCMOS 3.3 - Ethernet
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
