COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 467 www.cobham.com/gaisler
GR740
N2 ETH0_TXD[2] O LVCMOS 3.3 - Ethernet
N3 VSS3V3 Power/ground pin VSS3V3
N4 ETH0_TXEN O LVCMOS 3.3 - High Ethernet
N5 ETH0_TXCLK I LVCMOS 3.3 - Ethernet
N6 VSS3V3 Power/ground pin VSS3V3
N7 VDIG3V3 Power/ground pin VDIG3V3
N8 GND Power/ground pin GND
N9 VDD1V2 Power/ground pin VDD
N10 GND Power/ground pin GND
N11 VDD1V2 Power/ground pin VDD
N12 GND Power/ground pin GND
N13 VDD1V2 Power/ground pin VDD
N14 GND Power/ground pin GND
N15 VDD1V2 Power/ground pin VDD
N16 GND Power/ground pin GND
N17 VDD1V2 Power/ground pin VDD
N18 GND Power/ground pin GND
N19 VDIG3V3 Power/ground pin VDIG3V3
N20 VSS3V3 Power/ground pin VSS3V3
N21 VDIG2V5 Power/ground pin VDIG2V5
N22 SPW_RXS_P[3] I LVDS 2.5 DiffTerm Pos SpaceWire
N23 SPW_RXS_N[3] I LVDS 2.5 DiffTerm Neg SpaceWire
N24 SPW_RXD_P[3] I LVDS 2.5 DiffTerm Pos SpaceWire
N25 SPW_RXD_N[3] I LVDS 2.5 DiffTerm Neg SpaceWire
P1 ETH0_TXD[4] O LVCMOS 3.3 - Ethernet
P2 ETH0_TXD[6] O LVCMOS 3.3 - Ethernet
P3 VDIG3V3 Power/ground pin VDIG3V3
P4 ETH0_TXD[3] O LVCMOS 3.3 - Ethernet
P5 ETH0_TXD[1] O LVCMOS 3.3 - Ethernet
P6 VDIG3V3 Power/ground pin VDIG3V3
P7 VSS3V3 Power/ground pin VSS3V3
P8 VDD1V2 Power/ground pin VDD
P9 GND Power/ground pin GND
P10 VDD1V2 Power/ground pin VDD
P11 GND Power/ground pin GND
P12 VDD1V2 Power/ground pin VDD
P13 GND Power/ground pin GND
P14 VDD1V2 Power/ground pin VDD
P15 GND Power/ground pin GND
P16 VDD1V2 Power/ground pin VDD
P17 GND Power/ground pin GND
P18 VDD1V2 Power/ground pin VDD
P19 VSS3V3 Power/ground pin VSS3V3
P20 VDIG3V3 Power/ground pin VDIG3V3
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
