COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 468 www.cobham.com/gaisler
GR740
P21 VSS2V5 Power/ground pin VSS2V5
P22 SPW_TXS_P[2] O LVDS 2.5 - Pos SpaceWire
P23 SPW_TXS_N[2] O LVDS 2.5 - Neg SpaceWire
P24 SPW_TXD_P[2] O LVDS 2.5 - Pos SpaceWire
P25 SPW_TXD_N[2] O LVDS 2.5 - Neg SpaceWire
R1 ETH0_TXER O LVCMOS 3.3 - High Ethernet
R2 MEM_DQ[1] IO LVCMOS 3.3 - SDRAM
R3 VSS3V3 Power/ground pin VSS3V3
R4 ETH0_TXD[7] O LVCMOS 3.3 - Ethernet
R5 ETH0_TXD[5] O LVCMOS 3.3 - Ethernet
R6 VSS3V3 Power/ground pin VSS3V3
R7 VDIG3V3 Power/ground pin VDIG3V3
R8 GND Power/ground pin GND
R9 VDD1V2 Power/ground pin VDD
R10 GND Power/ground pin GND
R11 VDD1V2 Power/ground pin VDD
R12 GND Power/ground pin GND
R13 VDD1V2 Power/ground pin VDD
R14 GND Power/ground pin GND
R15 VDD1V2 Power/ground pin VDD
R16 GND Power/ground pin GND
R17 VDD1V2 Power/ground pin VDD
R18 GND Power/ground pin GND
R19 VDIG3V3 Power/ground pin VDIG3V3
R20 VSS3V3 Power/ground pin VSS3V3
R21 VDIG2V5 Power/ground pin VDIG2V5
R22 SPW_RXS_P[2] I LVDS 2.5 DiffTerm Pos SpaceWire
R23 SPW_RXS_N[2] I LVDS 2.5 DiffTerm Neg SpaceWire
R24 SPW_RXD_P[2] I LVDS 2.5 DiffTerm Pos SpaceWire
R25 SPW_RXD_N[2] I LVDS 2.5 DiffTerm Neg SpaceWire
T1 MEM_DQ[3] IO LVCMOS 3.3 - SDRAM
T2 MEM_DQ[5] IO LVCMOS 3.3 - SDRAM
T3 MEM_DQ[2] IO LVCMOS 3.3 - SDRAM
T4 MEM_DQ[4] IO LVCMOS 3.3 - SDRAM
T5 MEM_DQ[0] IO LVCMOS 3.3 - SDRAM
T6 VDIG3V3 Power/ground pin VDIG3V3
T7 VSS3V3 Power/ground pin VSS3V3
T8 VDD1V2 Power/ground pin VDD
T9 GND Power/ground pin GND
T10 VDD1V2 Power/ground pin VDD
T11 GND Power/ground pin GND
T12 VDD1V2 Power/ground pin VDD
T13 GND Power/ground pin GND
T14 VDD1V2 Power/ground pin VDD
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
