COBHAM GR740 User Manual

GR740-UM-DS, Nov 2017, Version 1.7 469 www.cobham.com/gaisler
GR740
T15 GND Power/ground pin GND
T16 VDD1V2 Power/ground pin VDD
T17 GND Power/ground pin GND
T18 VDD1V2 Power/ground pin VDD
T19 VSS3V3 Power/ground pin VSS3V3
T20 VDIG3V3 Power/ground pin VDIG3V3
T21 VSS2V5 Power/ground pin VSS2V5
T22 SPW_TXS_P[1] O LVDS 2.5 - Pos SpaceWire
T23 SPW_TXS_N[1] O LVDS 2.5 - Neg SpaceWire
T24 SPW_TXD_P[1] O LVDS 2.5 - Pos SpaceWire
T25 SPW_TXD_N[1] O LVDS 2.5 - Neg SpaceWire
U1 MEM_DQ[7] IO LVCMOS 3.3 - SDRAM
U2 MEM_DQM[1] O LVCMOS 3.3 - Low SDRAM
U3 VDIG3V3 Power/ground pin VDIG3V3
U4 MEM_DQM[0] O LVCMOS 3.3 - Low SDRAM
U5 MEM_DQ[6] IO LVCMOS 3.3 - SDRAM
U6 VSS3V3 Power/ground pin VSS3V3
U7 VDIG3V3 Power/ground pin VDIG3V3
U8 GND Power/ground pin GND
U9 VDD1V2 Power/ground pin VDD
U10 GND Power/ground pin GND
U11 VDD1V2 Power/ground pin VDD
U12 GND Power/ground pin GND
U13 VDD1V2 Power/ground pin VDD
U14 GND Power/ground pin GND
U15 VDD1V2 Power/ground pin VDD
U16 GND Power/ground pin GND
U17 VDD1V2 Power/ground pin VDD
U18 GND Power/ground pin GND
U19 VDIG3V3 Power/ground pin VDIG3V3
U20 VSS3V3 Power/ground pin VSS3V3
U21 VDIG2V5 Power/ground pin VDIG2V5
U22 SPW_RXS_P[1] I LVDS 2.5 DiffTerm Pos SpaceWire
U23 SPW_RXS_N[1] I LVDS 2.5 DiffTerm Neg SpaceWire
U24 SPW_RXD_P[1] I LVDS 2.5 DiffTerm Pos SpaceWire
U25 SPW_RXD_N[1] I LVDS 2.5 DiffTerm Neg SpaceWire
V1 MEM_DQ[9] IO LVCMOS 3.3 - SDRAM
V2 MEM_DQ[11] IO LVCMOS 3.3 - SDRAM
V3 VSS3V3 Power/ground pin VSS3V3
V4 MEM_DQ[10] IO LVCMOS 3.3 - SDRAM
V5 MEM_DQ[8] IO LVCMOS 3.3 - SDRAM
V6 VDIG3V3 Power/ground pin VDIG3V3
V7 VSS3V3 Power/ground pin VSS3V3
V8 VDD1V2 Power/ground pin VDD
Table 597.Pin assignment
Position Signal Name I/O Level
Vol t.
[V] Pull Polarity Note
