GR740-UM-DS, Nov 2017, Version 1.7 97 www.cobham.com/gaisler

GR740

9.4.10

Table 78. 0x34 - L2CSDEL - L2C Scrub delay register

Scrub delay register

9.4.11

Table 79. 0x38 - L2CEINJ - L2C Error injection register

Error injection register

31 16 15 0

RESERVED DEL

rrw

31: 16 RESERVED

15: 0 Scrub Delay (DEL) - Delay the scrubber waits before issue the next line scrub operation

31 210

ADDR R INJ

000

rw r rw

31: 2 Error Inject address (ADDR)

1: RESERVED

0 Inject error (INJ) - Set to ‘1’ to inject a error at “address”.
