4-4 ES45 Owner's Guide
To Remove Enclosure Panels from a Tower
The enclosure panels are secured by captive screws.
1. From the open position
, lift up and away to remove the front door
.
2. To remove the top panel, loosen the top left and top right screws
. Slide
the top panel back and lift it off the system.
3. To remove the left panel, loosen the screw
at the top and the screw
at
the bottom. Slide the panel back and then tip it outward. Lift it off the sys-
tem.
4. Go to Section 4.2 for instructions on removing covers from the system chas-
sis.
