Configuring and Installing Components 4-15
4.5 Power Supply Configuration
The system can have a single power supply (Model 2 has minimum of
two power supplies) or redundant configurations. You can add a
power supply for redundancy at any time without shutting down the
system.
Figure 4–5 Power Supply Locations
00
11
22
Tower
Pedestal/Rack
PK0207B
001
1
12
2
2
