1-16 ES45 Owner’s Guide
1.8.2 Model 2B
Model 2B has ten slots with six slots at 66 MHz and four slots at 33 MHz
(Model 2 uses the same configuration).
Figure 1–8 Location of I/O Slots: Model 2B (Pedestal/Rack View)
10-Slot
PCI
PK0226D
123 4 5 6 7 8 910
