4-36 ES45 Owner's Guide
Figure 4–18 PCI Card Installation (Pedestal/Rack View)
MR0027
5
4
6
1
2
7
3
CAUTION: Hot swap is not currently available with the ES45, however the
hardware is on the system. Do not press switch
or latch
on
thehot-swapboardwhenthesystemisrunning.Pressinganyof
these switches may result in loss of data.
Complete the following procedure to add or remove a PCI option card.
1. Turn off the system power.
2. Press in latch button
and open the latch.
3. Remove screw
if present.
