Configuring and Installing Components 4-21
4.8 Installing CPUs
Figure 4–9 CPU Card Installation (Pedestal/Rack View)
PK0240B
1
2
3
Slot 3
Slot 1
Slot 0
Slot 2
!
WARNING: To prevent injury, access is limited to persons who
have appropriate technical training and experience. Such per-
sons are expected to understand the hazards of working within
this equipment and take measures to minimize danger to them-
selves or others.
