Compaq AlphaServer ES45 1B - Chapter 1 System Overview

System Overview 1-1
Chapter 1
System Overview
This chapter provides an overview of the system, including:
• System Enclosures
• System Chassis—Front View/Top View
• System Chassis—Rear View
• Rear Ports and Slots
• Operator Control Panel
• System Motherboard
• I/O Backplane
• Power Supplies
• Removable Media Storage
• Storage Subsystem
• System Access
• Console Terminal
NOTE: See Chapter 4 for warnings and procedures for accessing internal parts
of the system.
