Configuring and Installing Components 4-29
!
WARNING: To prevent injury, access is limited to persons who
have appropriate technical training and experience. Such per-
sons are expected to understand the hazards of working within
this equipment and take measures to minimize danger to them-
selves or others.
!
WARNING: Do not remove memory modules until the green
LEDs are off (approximately 20 seconds after a power-down).
!
WARNING: Modules have parts that operate at high
temperatures. Wait 2 minutes after power is removed
before touching any module.
WARNING: To prevent injury, unplug the power
cord from each power supply before installing com-
ponents.
1. Shut down the operating system and turn off power to the system. Unplug
the power cord from each power supply.
2. Access the system chassis by following the instructions in Section 4.2.
3. Remove the fan cover and the system card cage cover.
4. Use Figure 4–11 or Figure 4–12 to determine where sets of memory DIMMs
should be installed. Begin with the next available lowest set.
5. Release the clips

securing the appropriate MMB

and slide out the
MMB. See Figure 4–13.
6. Release the clips

on the slot where you will install the DIMM.
See Figure 4–14.
Continuedonnextpage
