5-14 ES45 Owner's Guide
NOTE: The naming of devices (for example,dqa.0.0.15.0) follows the con-
ventions given in Table 5–8.
The slots in Example 5–2 are from the Model 2B ten-slot PCI backplane
and are explained below. An asterisk (*) indicates slots that contain a PCI
card.
Hose 0, Bus 0, PCI
Slot 7 On-board Acer chip. Provides bridge to Bus 1, ISA
Slot 8* VGA card
Slot 9* Bridge chip to Bus 2, PCI
Slot 10* Ethernet card
Slot 11* Ethernet card
Slot 12 Onboard PCI hot-plug controller
Hose 0, Bus 1, ISA
The floppy drive. It is the only device that comes from the bridge.
Hose 0, Bus 2, PCI
Slots 0–3 Onboard controllers.
Hose 1, Bus 0, PCI
Slot 1/0, 1/1* Two-channel SCSI card
(Slot 2) Not shown because no card installed.
Slot 6 Onboard PCI hot-plug controller
Hose 2, Bus 0, PCI)
Slot 1* Gigabit Ethernet card
Slot 2* Gigabit Ethernet card
Hose 3, Bus 0, PCI
Slot 1/0, 1/1* Two-channel SCSI card
(Slot 2) Not shown because no card installed.
