5-16 ES45 Owner's Guide
Table 5–7 How Physical I/O Slots Map to Logical Slots: Model 3B
Physical Slot SRM Logical ID (10-Slot Legacy PCI)
1
Hose 2 Slot ID 1
2
Hose 2 Slot ID 2
3
Hose 0 Slot ID 11
4
Hose 3 Slot ID 2
5
Hose 3 Slot ID 1
6
Hose 0 Slot ID 10
7
Hose 1 Slot ID 2
8
Hose 1 Slot ID 1
9
Hose 0 Slot ID 9
10
Hose 0 Slot ID 8
